The Eagle Talon
Eagle
Talon
74"-86"
Widths
50"
Opening
12+ Ton
Cylinder Force
Introduction
The eagle has landed. Grapple the toughest projects with ease.
The perfect blend of strength and weight, this grapple is made for quick clean up of brush, logs, and debris. Made for mid frame to large skid steers (75+ HP), the Eagle Talon takes massive bites out of large brush piles and back rakes small debris for faster clean-up . Dual 3" cylinders deliver over 12+ tons of force for crushing brush piles and grappling concrete. Simply put, this is the strongest, most versatile grapple in the industry.
Make Sure to Compare Grades of Steel
Some advertise "80 plate", This is a fancy name for Grade 36 Steel. They are marketing the maximum breaking strength of Grade 36 Steel which is 80,000 PSI/KSI. At Quick Attach we advertise our steel at the minimum bending strength, not maximum breaking strength. Don't be confused by grapples stating high tensile strength steel, if the grade isn't stated it is generally a mild Grade 36.
Key Features
Everything you need to get the job done right.
Gusseted Between Teeth
Gussets between teeth add extra strength, allowing the grapple to handle heavy loads and tough conditions with ease.
Two 3,000 lb. Cylinders
The two 3,000 lb. cylinders deliver powerful clamping force, ensuring secure gripping for heavy-duty tasks.
Replaceable Teeth Tips
Easily replaceable teeth tips reduce maintenance costs and extend the lifespan of the grapple.
Tighter Closure Than Conventional Grapples
Closes tighter than most grapples, offering better control and secure handling of smaller or awkward materials.
Specifications
Specs tough enough
for anything
Widths
74"-86"
Opening
50"
Cylinder Force
12+ Ton
| 74" | 86" | |
|---|---|---|
| Part Number | 901976 | 901977 |
| Cylinders | 3" x 8" (2) | 3" x 8" (2) |
| Cylinder Force | Over 12 Tons | Over 12 Tons |
| Grapple Teeth Lower | 7 | 8 |
| Grapple Teeth Upper | 12 | 12 |
| Height With Teeth Closed | 39.18” | 39.18” |
| Maximum Height With Teeth Open | 53.58” | 53.58” |
| Maximum Opening | 50” | 50” |
| Options | Bolt in Center | Factory Installed Couplers | Factory Installed Couplers | Bolt In Center |
| Steel Construction Of Teeth | Grade 50 | Grade 50 |
| Tine Length | 18" | 18" |
| Weight | 1,258 lb. | 1,385 lb. |
| Width | 75" | 87 |
| Width Between Teeth Lower Average | 12" | 12" |
| Width Between Teeth Upper Average | 12” | 12” |
CHECK COMPATIBILITYMachine not listed? Contact us for info on compatibility.
