Versa Grab
Versa
Grab
48"-60"
Jaw Opening
3"
Closes To
Optional
Winch
Introduction
Your perfect partner for moving moving trees, boulders, wood piles and more.
Boost productivity – Works on Both Front of Skid Steers, Tractors, and can also be mounted to the rear 3 point of tractors. Great for moving trees, boulders and large wood piles. With the Multi-Purpose Grapple, trees and debris can be delicately removed, repositioned, or loaded without damaging the surrounding landscape.
Key Features
Everything you need to get the job done right.
Skid Steer Mount and 3-Point Hitch Cat I and II
Compatible with both skid steer mounts and Cat I/II 3-point hitches, allowing easy attachment to various equipment.
Two Steel Steps for Traction
Sturdy steel steps with anti-slip surfaces provide safe access, ensuring secure footing in all conditions.
3-Inch Bore Cylinder
The 3-inch bore cylinder delivers powerful hydraulic force, ideal for heavy-duty lifting and clamping tasks.
Closes to Less Than 3 Inches
Closes to under 3 inches for a precise, secure grip on smaller objects, enhancing versatility and control.
Specifications
Specs tough enough
for anything
Jaw Opening
48"-60"
Closes To
3"
Winch
Optional
| 48" | 60" | |
|---|---|---|
| Part Number | 901315 | 901316 |
| Boom And Rotator Capacity | 9,000 lb. | 9,000 lb. |
| Grapple Cylinder Bore | 3" | 3" |
| Hydraulic Flow Requirements | 10 - 25 GPM | 10 - 25 GPM |
| Hydro Pressure Required | 2,000 - 3,000 psi | 2,000 - 3,000 psi |
| Maximum Jaw Opening Width | 48" | 60" |
| Minimum Jaw Closing Diameter | 3" | 3" |
| Mounting Plate | Universal, Cat I 3-Point, Cat II 3-Point | Universal, Cat I 3-Point, Cat II 3-Point |
| Operating Weight Manual Rotation | 1,129 lb. | 1,183 lb. |
| Options | Hydraulic Rotation Toplink Cylinder Winch Pistol Grip Control Harness* Loader Specific Wire Harness* Factory Installed Couplers *Applies to hydraulic model only | Hydraulic Rotation Toplink Cylinder Winch Pistol Grip Control Harness* Loader Specific Wire Harness* Factory Installed Couplers *Applies to hydraulic model only |
| Shipping Weight Manual Rotation | 1,179 lb. | 1,213 lb. |
| Winch Cable Length Actual Usable | 100 ’ / 85’ | 100 ’ / 85’ |
| Winch Capacity Optional | 12,000 lb. | 12,000 lb. |
CHECK COMPATIBILITYMachine not listed? Contact us for info on compatibility.
