Quick Push
Quick
Push
4
Trip Springs
3/8" x 6"
Cutting Edge
Universal
Mounting Plate
Introduction
Snow doesn't stand a chance.
The Snow/Light Material Blade is the perfect way to remove snow from walks, driveways, or parking lots. Use it in the summer for light material grading by engaging the standard locking trip mechanism. Add the optional Wing Kit and your blade becomes a snow pusher, increasing your production of larger areas and lots.
Key Features
Everything you need to get the job done right.
Four Trip Springs
Provides protection and strength by allowing the blade to pivot over obstacles.
Visible Guide Markers
Easily locate the blade edge for improved precision during operation.
Easy-Adjust Depth Shoes
Quickly customize the cutting depth for various snow conditions.
25° Manual or Hydraulic Angling
Offers versatile blade angling for efficient snow removal.
Specifications
Specs tough enough
for anything
Trip Springs
4
Cutting Edge
3/8" x 6"
Mounting Plate
Universal
| 72" | 84" | 96" | 108" | |
|---|---|---|---|---|
| Part Number | 900341 / 900340 | 900343 / 900342 | 900345 / 900344 | 900347 / 900346 |
| Angling | Manual / Hydraulic | Manual / Hydraulic | Manual / Hydraulic | Manual / Hydraulic |
| Cutting Edge | 3/8” x 6” | 3/8” x 6” | 3/8” x 6” | 3/8” x 6” |
| Cylinders | 3 x 8 | 3 x 8 | 3 x 8 | 3 x 8 |
| Height | 28” | 28” | 28” | 28” |
| Moldboard Thickness | .135” | .135” | .135” | .135” |
| Mounting Plate | Universal | Universal | Universal | Universal |
| Operating Weight | 600 lb. | 635 lb. | 670 lb. | 705 lb. |
| Options | Urethane Cutting Edge Rubber Cutting Edge Urethane Skid Shoes Wing Kit Factory Installed Couplers | Urethane Cutting Edge Rubber Cutting Edge Urethane Skid Shoes Wing Kit Factory Installed Couplers | Urethane Cutting Edge Rubber Cutting Edge Urethane Skid Shoes Wing Kit Factory Installed Couplers | Urethane Cutting Edge Rubber Cutting Edge Urethane Skid Shoes Wing Kit Factory Installed Couplers |
| Shipping Weight | 675 lb. | 710 lb. | 745 lb. | 780 lb. |
| Trip Springs | 4 | 4 | 4 | 4 |
| Trip Type | Moldboard | Moldboard | Moldboard | Moldboard |
| Width | 72” | 84” | 96” | 108” |
| Width Fully Angled | 66” | 76” | 87” | 98” |
CHECK COMPATIBILITYMachine not listed? Contact us for info on compatibility.
