Quick Sweep Mini
Quick Sweep
Mini
25°
Right/Left Angling
7–17 GPM
Rated Flow
2,000–3,000 psi
Operating PSI
Introduction
Your ultimate cleanup companion.
The Mini Power Angle Broom is designed for heavy-duty sweeping of dirt, snow, and other unwanted material. It quickly mounts to your mini skid steer. Featuring a 48” width and optional hydraulic angle change, this attachment is designed to go anywhere to get the job done!
Key Features
Everything you need to get the job done right.
Direct-Drive Design
Efficient power transfer with reduced maintenance and improved reliability.
Optional Power Angling
Quick blade angle adjustments from the cab for enhanced efficiency.
25° Angling Capability
Versatile blade angles for precise snow management and maneuverability.
Standard Storage Stands
Convenient storage support for easy maintenance and secure storage.
Specifications
Specs tough enough
for anything
Right/Left Angling
25°
Rated Flow
7–17 GPM
Operating PSI
2,000–3,000 psi
| 48" | 60" | |
|---|---|---|
| Part Number | 900890 | 901578 |
| Bristle Diameter | 24” | 24” |
| Description | Manual Angling w/poly | Manual Angling w/poly |
| Hydraulic Flow Requirements | 7-17 GPM | 7-17 GPM |
| Maximum Angle Both Ways | 25° | 25° |
| Mounting Kit Configurations | ASV/Terex (RC/PT30) Bobcat (MT-52/55, 463/S70) Toro / Vermeer / Boxer / Ditch Witch / Ramrod / Kanga / Cormidi Universal Mounting Plate (up to 1,000 lb. ROC and within rated flow) | ASV/Terex (RC/PT30) Bobcat (MT-52/55, 463/S70) Toro / Vermeer / Boxer / Ditch Witch / Ramrod / Kanga / Cormidi Universal Mounting Plate (up to 1,000 lb. ROC and within rated flow) |
| Operating Pressure | 2,000 - 3,000 psi | 2,000 - 3,000 psi |
| Options | Toggle Control Harness* Loader Specific Wire Harness* Factory Installed Couplers * Applies to hydraulic model only 48 - Manual Angling w/steel - 901300 48 - Manual Angling w/poly/steel - 900891 48 - Hydraulic Angling w/poly - 900892 48 - Hydraulic Angling w/steel - 901301 48 - Hydraulic Angling w/poly/steel - 900893 48 - Hydraulic Angling Reversible w/poly - 900888 48 - Hydraulic Angling Reversible w/steel - 901302 48 - Hydraulic Angling Reversible w/poly/steel - 900889 | Toggle Control Harness* Loader Specific Wire Harness* Factory Installed Couplers * Applies to hydraulic model only 60 - Manual Angling w/steel - 901580 60 - Manual Angling w/poly/steel - 901579 60 - Hydraulic Angling w/poly - 901581 60 - Hydraulic Angling w/steel - 901583 60 - Hydraulic Angling w/poly/steel - 901582 60 - Hydraulic Angling Reversible w/poly - 901584 60 - Hydraulic Angling Reversible w/steel - 901586 60 - Hydraulic Angling Reversible w/poly/steel - 901585 |
| Overall Width | 58.5” | 70.4" |
| Weight | 325 lb. | 385 lb. |
| Working Width | 48” | 60" |
| Working Width 25 Angle | 43.5” | 54.4" |
CHECK COMPATIBILITYMachine not listed? Contact us for info on compatibility.
